1200t Kobelco Cold Forging Press
High-Capacity Cold Forging Press for Industrial Parts
Description
Technical Details KOBELCO 1200t
General Information:
- Manufacturer: Kobelco
- Model: LCF-1200
- Year of Manufacturing: 1983.
- Type: Cold Forging Press
- Forming Stages: 1
- Press Size:
- Width: 3M
- Height: 9M
- Press Weight: Approximately 190t
Specifications:
- Die Height: 800 mm
- Slide Dimension (Left to Right): 1000 mm
- Slide Dimension (Front to Back): 1200 mm
- Bolster Dimension (Left to Right): 1000 mm
- Bolster Dimension (Front to Back): 1200 mm
- Thickness: 200 mm
- Slide Adjustment Length: 30 mm
- Stroke Length: 500 mm
- Number of Strokes: 15-20 spm (strokes per minute)
- Maximum Workload: 30 TON-M at 15 SPM
- Main Motor: 170Kw/DC
Auxiliary Equipment:
- 1. Material Feeding Device:
- Manufacturer: Yoshishin Industry
- Date of Introduction: May 1990
- 2. One-Component Lubricant Applicator:
- Manufacturer: RCD Techno
- Type: Rotating Drum
- Date of Introduction: March 2004
- 3. Local Exhaust Ventilation:
- Manufacturer: Nitto Kakoki
- Type: Steam Exhaust Fan
- Date of Introduction: July 2001
- 4. Automatic Transport Mechanism (Loader/Unloader):
- 5. QDC (Die Exchange Device):
- Manufacturer: Kobe Steel
- Date of Introduction: June 1983
- Remarks: Die set (1 upper/2 lower)
- 6. Exit Dispensing Device:
- Manufacturer: Yoshishin Industry
- Date of Introduction: June 1983
- 7. LA Furnace Loading Synchronous Conveyor:
- Manufacturer: Yoshishin Industry
- Total Length: Approximately 6M
- Date of Introduction: September 1990
- 8. Dust Collector:
- Manufacturer: Asahi Electric Industry
- Type: Dry Method
- Date of Introduction: March 2003
- 9. Current Monitoring Device:
- Manufacturer: HM (In-house production)
- Function: Current/Temperature Monitoring
- Date of Introduction: March 2003
- 10. Oil Applicator:
- Date of Introduction: March 2018
- Date of Introduction: March 2018
- 11. Jib Crane:
- Load Capacity: 490 kg
- Arm Length: Approximately 2.6M
- Date of Introduction: April 1983
Facility Features:
- Control Panel: Located on the second floor
- Underground Pit: Accommodates one hydraulic unit
- Press Accessory Equipment Overview
Press Weight:
- Reference Value: Approximately 190 tons
