Central Coolant Treatment System
Central Coolant Filtration & Treatment System
Description
Coolant Filter System - Knoll VL 1500-E/8200
- Type: VL 1500-2/14000
- Vacuum filter 2 PC
- Type: VL 1500-E
Technical specifications:
- Length 2520 mm
- Width 1900 mm
- Height 1560 mm
- Filter performance max. 1200 l/min per filter unit
Equipment:
- Power consumption 6 kW
- Gear motor for belt drive 0,25 kW in conveying direction right
- Controlled filter pump 3 kW
- Controlled vacuum pump 2.2 kW
- Level Measurement by WHG
- Filter media Endless filter belt LAM-PET-74
- A high proportion of very fine particles ( Total trash content may require the use of filter fabric or filter aid with cellulose.
- Cleaning mechanically
- Distance from apron to the safety collection tank 400 mm
- Distance from apron to floor 1200 mm
- Membrane pump 1 PC
- Type: TX25ANN
- Membranpumpe G1/2" NBR with suction lance placed between the two VL-tops for the extraction of chips carriage
- Flow rate 500 l/h max. 0-1500 l/h adjustable
- Operating pressure max. 10 bar
- Solids size max. 3 mm
- Tank 1 PC
- Type: FKA/14000
Technical data/execution:
- Length 7300 mm
- Width 2400 mm
- Overall height 1200 mm
- Content 14000 l
- Ground clearance 100 mm
- Tank cover
- Steel sheet
