102. (1979) 630t Gräbener Knuckle-Joint Press
Gräbener GK 630 NS
Industrial Knuckle-Joint Press for High-Force Cold Forming
This Gräbener press utilizes a knuckle-joint mechanism to deliver exceptional force, making it highly effective for precision coining and embossing. With a massive 27,000 kg frame and a 28 kW motor, it provides the stability required for heavy-duty metalworking operations.
Industry
Forging
Sale Type
Private Treaty
Manufacturer
Gräbener
Country
Germany
Machine Type
Knuckle-Joint Press
Year of Manufacture
1979
Model
GK 630 NS
Nominal Force
630t
Technical Details
- Machine Type: Knuckle-Joint Press
- Manufacturer: Gräbener
- Model: GK 630 NS
- Year of Manufacture: 1979
- Nominal Capacity: 630t
- Stroke Rate: 45 strokes/min
- Shut Height: 420 mm
- Tool Holder Adjustment: 80 mm
- Clearance Between Uprights (Frame Width): 820 mm
- Table Area (Width x Depth): 800 mm x 850 mm
- Motor Output: 28 kW
- Motor Speed: 1,475 rpm
- Operating Voltage: 3x 380V / 220V, 50Hz
- Total Weight: 27,000 kg
- Overrun Time (Stopping Time): 160 ms
- Safety Distance: 266 mm
