90. (1973) 180t Gräbener Knuckle-Joint Press
Gräbener GK 180
Precision Knuckle-Joint Press for Detailed Cold Forming
This 1973 Gräbener model utilizes a knuckle-joint mechanism to deliver high pressing force with controlled ram speed, making it ideal for precision coining and embossing tasks. It features a compact design with a 180-ton capacity and is equipped with a 5.5 kW motor for reliable industrial operation.
Industry
Forging
Sale Type
Private Treaty
Manufacturer
Gräbener
Country
Germany
Machine Type
Knuckle-Joint Press
Year of Manufacture
1973
Model
GK 180
Nominal Force
180t
Technical Details
- Machine Type: Knuckle-Joint Press
- Manufacturer: Gräbener
- Model: GK 180
- Year of Manufacture: 1973
- Nominal Force: 180t
- Stroke: 50 mm
- Stroke Rate: 40 strokes/min
- Shut Height: 305 mm
- Tool Holder Adjustment: 40 mm
- Clearance Between Uprights: 390 mm
- Table Area (Width x Depth): 370 mm x 450 mm
- Tool Holder Mounting Surface (Width x Depth): 360 mm x 200 mm
- Tool Holder Shank Hole (Ø x Depth): 40 mm x 75 mm
- Motor Output: 5.5 kW
- Motor Speed: 1,450 rpm
- Operating Voltage: 3x 380V / 220V, 50Hz
- Overrun Time (Stopping Time): 297 ms
- Safety Distance: 310 mm
