93. (2013) 400t Müller Knuckle-Joint Press
Müller KNP 400
Precision Knuckle-Joint Press for High-Speed Forming
This year-2013 Müller press provides a 4,000 kN pressing capacity and a high-efficiency 55 strokes per minute cycle rate. Engineered for modern industrial precision, it features safety response times suitable for high-volume production environments.
Industry
Forging
Sale Type
Private Treaty
Manufacturer
Müller
Country
Germany
Machine Type
Knuckle-Joint Press
Year of Manufacture
2013
Model
KNP 400
Nominal Force
400t
Technical Details
- Machine Type: Knuckle-Joint Press
- Manufacturer: Müller
- Model Type: KNP 400
- Machine Number: 2703
- Year of Manufacture: 2013
- Nominal Force: 400t
- Work Capacity: 13 kJ
- Ram Stroke: 70 mm
- Ram Adjustment: 45 mm
- Stroke Rate: 55 strokes/min
- Shut Height (Table to Ram): 380 mm (Stroke down, adjustment up)
- Ram Surface Area (W x D): 500 mm x 400 mm
- Table Surface Area (W x D): 500 mm x 500 mm
- Motor Output: 15 kW
- Operating Voltage: 400 V
- Safety Distance: 190 mm
- Limit Value (Stopping Time): 95 ms
- Total Weight: 16,500 kg (16.5 metric tons)
- Machine Dimensions (W x D x H): 1.7 m x 2.4 m x 3.0 m
